Fit - Column Fixture

Fitnesse Architecture


ColumnFixture maps table columns directly to:

  • properties,
  • methods
  • and fields

of the fixture class.

It is very useful for repetitive verification (as parameterized test) if the same test needs to be repeated for different combinations of input arguments.

Similar to Slim - Decision Table (test case as a row)


  • The first row of the table is the fixture test class name.
  • The second row map column names to a field or method (where the Output values must have a question mark ? after the column name).
  • All following rows list combinations of input arguments and expected values of output arguments.



|Hello|World|Hello, World|10|
|Houston|We Have a Problem|Houston, We Have a Problem|24|


  • info.fitnesse.fixturegallery.ColumnFixtureTest is the class to test
  • firstPart and secondPart are the input value
  • together and totalLength'' are the ouput tested
  • the test data is
|Hello|World|Hello, World|10|
|Houston|We Have a Problem|Houston, We Have a Problem|24|

Example of test class:

package info.fitnesse.fixturegallery;

import fit.ColumnFixture;

public class ColumnFixtureTest extends ColumnFixture {
	public String firstPart;
	public String secondPart;
	private int length;
	public String together(){
		return firstPart+ ", "+secondPart;
	public int totalLength(){
		return length;


Documentation / Reference

Discover More
Fitnesse Architecture
Slim - Decision Table (test case as a row)

A decision table is a language structure of Fitness that defines tests run and expectation. Similar to Fit Column Fixture See Basic test with a decision table where eg.division is the fixture...
