Javascript Event Targets (DOM)

target

event.target returns the object to which event is dispatched (its target). Ref.

This is:

• for an implicit dispatch: ie event handler (ie on event), the element where the handler is defined
• for an explicit dispatch: the element where the dispatchEvent function is called

currentTarget

currentTarget returns the object whose event listener’s callback is currently being invoked. Ref

This is:

• for a explicit event listener (ie addEventListener), the element where the listener is added.

relatedTarget

The related target gets the elements that has focus when the event occurs.

• ie a HTML element that has natively focus such as an anchor or a button
• or an element with the tabindex property set to 0 or more.

You will get it for instance in a blur event.

Implicit Dispatch

You have an implicit dispatch when your event propagate (ie bubble).

Demo:

• The button that will be clicked and a div where the event will propagate.

<div>
    <button>Click me</button>
</div>

• The callback function called on the click event

function printNodeNameCallback(e) {
     console.log('-------------------');
     console.log("Target: "+e.target.nodeName.toLowerCase());
     console.log("Current Target: "+e.currentTarget.nodeName.toLowerCase());
}

• Attach event listener to the div and button element

document.querySelector("div").addEventListener("click", printNodeNameCallback);
document.querySelector("button").addEventListener("click", printNodeNameCallback);

• Result:
  • the first callback is executed with the button as currenttarget
  • the second callback is executed with the div as currenttarget showing that the event has propagated

Explicit dispatch

• The HTML code. We will execute an event against the world span.

<p>Hello <span id="world">world</span>!</p>

• Utility function to print the node id

function getNodeId(node){
  let nodeId = node.nodeName;
  if ("id" in node){
     nodeId += "#"+node.id;
  }
  return nodeId.toLowerCase();
}

• A callback function that will give as listener parameter to be executed when the event is dispatched

function eventCallback(e) {
     console.log('-------------------');
     console.log("Target: "+getNodeId(e.target));
     console.log("Current Target: "+getNodeId(e.currentTarget));
     console.log("Event Phase: "+e.eventPhase);
}

• The custom event type (ie event name)

let eventName = "myEvent";

• Add two listeners on document and body that executes the callback for this event

document.addEventListener(eventName , eventCallback, {capture: true})
document.body.addEventListener(eventName , eventCallback)

• Create the event and dispatch it against the span world element

var myEvent = new Event(eventName, {bubbles:true})
document.getElementById("world").dispatchEvent(myEvent)

• Result:
